Spezifikationen
Battery
Core S2, 720 Wh, 36 V
Battery capacity
720 Wh
Brake lever
Shimano BL-M8100, Bremshebel einstellbar, 2-Finger
Break (front)
Shimano BR-M8120, 4-Kolben, Hydraulische Scheibenbremse
Break (rear)
Shimano BR-M8120, 4-Kolben, Hydraulische Scheibenbremse
Break disk (front)
Shimano SM-RT64, 220 mm, Center Lock
Break disk (rear)
Shimano SM-RT64, 203 mm, Center Lock
Break disk type (rear)
Hydraulische Scheibenbremse
Chain
KMC e12S
Chain guide
Husqvarna CGU
Chainring
Husqvarna, Narrow Wide, 34 T
Clamp
Husqvarna 34,9, Innensechskant
Control unit
Shimano SW-EM800-L
Crank arm
Shimano FC-EM900, Aluminium geschmiedet, Shimano EP24
Damper
FOX Float X2 Factory, Luft, 230x65 mm
Derailleur
Shimano XTR, RD-M9100, Shadow Plus, 12-S
Display
Shimano SC-EM800, LCD-Display, ANT, Bluetooth
Engine
Shimano EP8, DU-EP800, 250 W, 85 Nm
Fork
FOX Float 38 Factory, Grip 2, E-Optimized, Luft, 180 mm, tapered
Frame
29/27.5", Alloy 6061, integrierter Akku, Boost, New HQV Alloy, 170 mm
Frame material
Aluminium
Gear shift
Kettenschaltung
Grips
Husqvarna MTB, Schraubgriffe
Handlebar
Husqvarna Riser 35 mm, 780 mm, Sweep: 9 °, Rise: 20 mm
Headset
Acros ICR, blocklock, ZS56/ZS56
Model year
2022
Pedals
Husqvarna, Aluminium
Permitted total weight
130 kg
Recharger
Charger S, 4 A
Seat post
Husqvarna Pro, 31,6 mm, Dropper Post
Shift box
Shimano CS-M6100, 10-51 T
Shift Lever
Shimano XTR, SL-M9100, Rapidfire Plus
Spring stroke
180 mm
Spring stroke frame
170 mm
Stem
Husqvarna 35, 0 °, Ahead
Stvzo
STVZO Nein
Terrain
Gelände
Tyre
Schwalbe Magic Mary, Evolution, 62-622, 29x2.4, Tubeless Ready
Tyre (rear)
Schwalbe Hans Dampf, Evolution, 65-584, 27.5x2.6, Tubeless Ready
Wheel set
DT Swiss HX 1700 SPLINE, Tubeless ready, 6-Loch, 15x110/12x148 mm, Steckachse
Wheel size
27.5“/584mm, 29"/622mm
